When 30 s is finished, after entering the automatic rinsing stage, after cleaning for 3 minutes, then draining
f
or 30 s, the tap water rinsing process for 2 times, then using pure water rinsing cycle 3 times, the whole
leaning process is over, The screen shows "OFF", into standby state and unplug" after 37 minutes of
leaning.
ote: After cleaning and disinfection, start making ice, the first 5 plates of ice discarded, do not eat.
5.3 Parts Removal/Installation Process
When removing the pipe, remove the "pipe fixing support" and "clamps "(as shown)
Removing Water Pipe Fixed Support
To Next Page
