 Appearance
①.
②. Pannel
③. Front plate
④. Right side plate
⑤. Door
⑥. Adjustable feet
⑦. Power supply cable
⑧. Inlet value
⑨. Condernser
⑩. Back plate
11. Purge pipe connector
12. Left side plate
13. Purge pipe connector
1
7
2
3
4
5
6
8
11
9
10
13
12
11
12
13
Top cover plate
