Cover Pools Save-T 3 - Additional Housing Options

All diagrams are for general information. Consult installation instructions for details.
10
Deck-Mounted Bench Construction
Deck-Mounted Fiberglass Ends
Three-piece adjustable steel
brackets provide a maximum height
of 20" by 24" wide. Surface material
is not included.
Fiberglass ends are an economical and
practical solution to cover the deck-mounted
mechanism. Available in white.
roller tube
Recessed Wood Box Construction
Requirements:
The material used to construct the box should be:
2" x 12" pressure-treated lumber or redwood
Upper trim:
2" x 4" pressure-treated lumber or redwood
side
view
side
view
top
view
top
view
side view
14½"
12½"
14½"
36"
12"
24"
12"
to
braces
12½"
Also available with
stainless-steel base.
16¼"
to
17½"
20"
Everlast
™
Bench Kit
Bench Frame
Modular bench kit uses adjustable-
height brackets and polymer panels
to create a low-maintenance bench
system.
Available in 4 colors
Recessed Concrete, Wood, or UPB Box—Universal or SnapTop™ Track
B
W
D
O
M
POOL
conduit 6" max
from top
of box
conduit should not
protrude more
than 4" into box
conduit must be on the
motor end
3" drain - floor or wall
can be on either end
wall cut away for clarity
bond wire
pool beam wall
drain centerline 4"
max from end wall
bond wire
Deck Mount Track
Box Dimensions for Save-T
®
3
MOTOR
M
OPPOSITE
O
BEAM
B
THROAT
T
DEPTH
D
WIDTH
W
Pools under 55 ft. long x 24 ft. wide 32" 10" 8-12" 2" min to finished beam 12½" min 12½" min
UPB BOX Pools up to 55 ft. long
32" 10" 8-12" 2" min to finished beam 13" 13"
Pools over 55 ft. long x 24 ft. wide 32" 10" 8-12" 2" min to finished beam 14½" 14½"
Pools over 65 ft. long or 25 ft. wide and vanishing-edge pools — Call Cover-Pools 1-800-447-2838
Consult a certied
electrician and the
pre-wiring diagrams for
conduit and bonding
requirements.
