All diagrams are for general information. Consult installation instructions for details.
2
All exposed aluminum extrusions can be painted to match
deck color.
SnapTop™ Track
• For existing decks
• Low profile
• Installed on the deck surface
• Anodized aluminum
• Uses gliders or wheels
• Screws are concealed
• Standard Universal track
also available
• Smaller Slim™ track
available for Step-Saver™
systems
Flush Track - NEW
• For new or existing pools
• Installed flush with deck
• Vinyl-liner, fiberglass or
concrete pools
• Anodized aluminum
Universal Deck-Mounted
Track
• For existing decks
• Low profile
• Installed on surface of
the deck
• Anodized aluminum
Deck-on-Deck Pools
Create a rectangular frame
around the free-form pool for
an undertrack installation with
track channel.
track channel or
deck straps
Extreme Cantilever
Create a freeform pool by ex-
tending the cantilever up to 24"
beyond the channel or track.
track channel or
deck straps
2-13/16"
11/16"
Vanishing-Edge Pools
Perimeter Overflow
Create a 45° or 90° vanishing edge
Create a pool for which water height appears even with
the deck. A narrow channel collects the overflow water
and allows for the glider arms.
600198 ILLUS VAN EDGE 45 DEG COVER OPENING DETAIL - DWG1
Universal track for spas
and Step-Saver
45° 90°
Recommended for Indoor use only
2-13/16"
11/16"
1-1/2"
3-1/2" – 4"
Special Construction Applications
