Coway CHP-06DL Service Manual

Disassembling and refitting
4-6
Coway co., Ltd
No. Part name Explanation Reference picture
3 Switch knob 1) Separate the switch knob by
pulling the 6 hooks of
f the front
PBA.
2)
Remove the switch knob.
4
Cock deco
assy
1)
Remove the 2 screws from both
sides of the front deco.
: 2-4x12 T
AP
2) Remove the front deco by
pressing both sides of it hard in
the direction of the arrows.
