Coway CHP-06DL Service Manual

Exploded view of the system and the list of service parts
6-3
Coway co., Ltd
6-2 Service parts list of CHP-06DL
Code No. Description Specification Q’ty Remark
110244
POST-CARBON FILTER-BLOCK
8INCH(S)
8INCH 1
110207 MEMBRANE FILTER-RO 8INCH(S) 8INCH, 20GPD 1
110245
NEOSENSE FILTER-8INCH(S) 8iNCH 1
3106863 BASE ASSY(CHP-06DL) 1
3106873
COMPRESSOR (HSL5Y-4P)
(CHP-06DL)
HSL5Y-5P
R-134a 220-240V
50Hz
1
3106660
COMPRESS HARNESS ASSY
(CHP-06DL)
1015 A
WG20 1
3106005 WIRE CONDENSER
ASSY 1
3105731
BOX PAN(CHP-06DL) 1
3104300
BOX PAN BRACK (CHP-05AL)
MU30 1
3103154 FILTER DR
YER (CHP-06DL) Φ19(XH-9,10g) 1
3106007 CAPILLARY
TUBE (CHP-06DL) Φ1.8x0.55tx1440 1
3002129 CHARGE PIPE (DW,CHP-8800)
C1220T(Φ4.76X0.7t) 1
3106008 NBR HOSE (CHP-06DL) Φ18 ×Φ9 ×400mm 1
3106009 NBR HOSE H (CHP-06DL) Φ35 ×Φ23 ×150mm 1
3106012 FEED+NOS VAL
VE ASSY (CHP-06DL) 1
3106622 MAIN PBA
ASSY 1
9001757 MAIN PBA P
ACKING BOX 240*130*85, WJB-PS0010 1
9001767 SHIPPING PACKING BOX 495*460*275, WJB-TS0004
1
3106874 POWER CORD ASSY 16A
250V 1
3106015 3WA
Y VALVE ASSY (CHP-06DL) DC24V 1
3106875 HEATING
TANK ASSY (CHP-06DL) 220V,300W 1
3106017
Silicone H/T->3WAY VALVE (CHP-06DL) 1
3106018
OVER HEATING SILICONE HOSE
(CHP-06DL)
φ12 x φ8 1
3001697
Silicone(M/T->H/T)
ASSY (CHP-01B) 1
3106019 DRAIN CONNECTOR
ASSY 1
3002296
DRAIN CONNECOTOR4-RED
(CHP-01AL)
Φ22x8.5 1
3106020 MAIN T
ANK ASSY(CHP-06DL) Assy 1
3106021
Silicone M/T->3WAY VALVE
(CHP-06DL)
Φ14, 1.5t 1
3106022 REED LEVEL SENSOR(CHP-06DL)
2 STEP 1
9206215
REED LEVEL SENSOR P
ACKING
VINYL
190*150 1
CHP-06DL-eng.indb 3 2007-10-22 ｿﾀﾀ・9:13:26
