Coway CHP-06DL Service Manual

Exploded view of the system and the list of service parts
Coway co., Ltd
6-4
9206216 REED LEVEL SENSOR IN BOX 135*45*44 1
9206217 REED LEVEL SENSOR OUT
BOX 480*410*320 1
3106023 OVER FOLW SENSOR (CHP-06DL)
1 STEP 1
9206218
OVER FOLW SENSOR P
ACKING
VINYL
95*150 1
9001758
LOW WA
TER LEVEL SENSOR
PACKING BOX
65*40*55 1
9001768 SHIPPING PACKING BOX 325*410*160 1
3106024
COLD WA
TER SENSER ASSY
(CHP-06DL)
1
3106025 COOLING COIL
ASSY (CHP-06DL) 1
3106026
COOLING T
ANK INSULATION FRONT
(CHP-06DL)
1
3106027
COOLING T
ANK INSULATION REAR
(CHP-06DL)
1
3104678 PRESS SEALANT (CHP-06DL)
50X20X2T 3
3106028 INSULATION (CHP-06DL) 80 X 250 X 3t 1
3106029
SEPARA
TOR BOARD (CHP-06DL) JI360 - 3685T 1
3106030 REAR COVER ASSY
(CHP-06DL) 1
3106876 MAIN PBA COVER
ASSY 1
3106032 SIDE COVER R ASSY
(CHP-06DL) 1
3106033 SIDE COVER L
ASSY 1
3106034 SIDE DOOR ASSY
(CHP-06DL) 1
3107912 FRONT COVER
ASSY (CHP-06DL) 1
3207663 FRONT DECO (CHP-06DL) LG HF380P
A-8D377 1
3202396 FRONT COVER (CHP-06DL) LG HF380G-07497B 1
3202397
DISPLAY
WINDOW (CHP-06DL) 2
3202398 COCK DECO ASSY
(CHP-06DL) 1
3202404 FRONT PBA
(CHP-06DL) 1.6t,LED S/W,CD 1
9001956 FRONT PBA
PACKING BOX 180*130*70, WJB-PS00062 1
9001969 SHIPPING PACKING BOX 555*370*275, WJB-TS0051
1
3202405 FND ASSY
(CHP-06DL) Assy 1
3202408 LOCK KNOB (CHP-06DL) LG HF380PA-8D377, SPRA
Y 1
3202409 SWITCH KNOB ASSY
(CHP-06DL) Assy 1
3202411
FROTN PBA EXTENTION CABLE
(CHP-06DL)
UL1007 A
WG22 1
3202412 COCK PBA
CABLE (CHP-06DL)
UL1007 AWG22 4P to 4P 1
Code No. Description Specification Q’ty Remark
CHP-06DL-eng.indb 4 2007-10-22 ｿﾀﾀ・9:13:26

Coway CHP-06DL Specifications

General

Brand	Coway
Model	CHP-06DL
Category	Water Filtration Systems
Language	English
