Coway CHP-06DL Service Manual

Exploded view of the system and the list of service parts
6-5
Coway co., Ltd
Code No. Description Specification Q’ty Remark
3106036 MIAN TANK CAP ASSY (CHP-06DL) 1
3106037 TOP
COVER ASSY (CHP-06DL) 1
3106041 TRAY
ASSY (CHP-06DL) 1
3003874 COOLING STOPPER (CHP-7500) 1
3016359
TAP
HOSE ASSYⅡ 1M 1
3007276 ADAPTER ASSY 1/2INCH 1
3201755
ADAPTER ASSY
BOX 1
3201765 ADAPTER SHIPPING PACKING BOX 1
3000611
AUT
OMATION DRAIN CONTROL
VALVE
ELBOW, GRAY 1
3000464 TUBING ORANGE LLDPE, 1/4INCH 1.005 m
3000463 TUBING BLUE LLDPE, 1/4INCH 0.79 m
3000482 ELBOW FITTING 1/4INCH 6
3000485 STEM ELBOW FITTING 1/4INCH 3
3015790 STRAIGHT
FITTING 1/4INCH 2
3105660
ELBOW CHECK VAL
VE ASSY 1
3105892 CERAMIC FILTER 1
CHP-06DL-eng.indb 5 2007-10-22 ｿﾀﾀ・9:13:27

Coway CHP-06DL Specifications

General

Brand	Coway
Model	CHP-06DL
Category	Water Filtration Systems
Language	English
