Fault diagnosis
Coway co., Ltd
5-5
5-2 Control specifications
Hot water
tank
Main PBA
3WA
Y V/V
FEED+NOS
V
alve
W
ater overflow
sensor
Reed level
sensor
Cold water
thermistor
