Coway CHP-06DL Service Manual

1 3
2
4
1
2
3 4
6
5 6 7
5
8
Fault diagnosis
Coway co., Ltd
5-7
3) Operation part and indication part
1 Indication Part
2 Operation Part
1 Hot water lock button
2 Hot water button
3 Room water button
4 Cold water button
5 Extraction cock
6 Cold/hot/room
temperature water
Extraction button
1 Hot water mode lamp/
hot water 3 step LED
2 Hot water lock on
3 Cold water mode lamp/
cold water 3 step LED
4 Light detection sensor
5 Hot water LED
6 Room water LED
7 Cold water LED
8 Extraction indicator LED
