Power saving function
The compressor and heater are controlled according to the outside illumination by reading the CDS
value. (The power saving mode is is turned on when detecting 1 lux or lower for 10 minutes.)
To use the power saving function, it should be activated in the setting mode.
Illumination
CDS
resistance
value
Cooling fan Compressor operation Heater operation
1 lux or higher
(in normal
mode)
165
KΩ or
lower
1800 RPM
+/- 15%
5°C detected and
then it is turned off 17
minutes later
.
7.3°C ON
96°C detected and
then it is turned of
f
1 second later.
91
°C ON
1 lux or lower
(Power saving
mode)
165
KΩ or
higher
1800 RPM
+/- 15%
5°C detected and
then it is turned off 17
minutes later
.
10°C ON
96℃ detected and
then it is turned of
f
1 second later.
70
°C ON
In the power saving mode, the cooling fan starts when the compressor operates for the first time and
then it operates at 1800 RPM +/- 15%.
The cooling fan operation is linked with the compressor operation.
Selection and extraction functions (set quantity and continuous extraction)
The quantity of the extracted water is adjusted by controlling the 3-way valve according to the time
detected by the extraction switch.
1.2pF or higher
Upper part of the
Non-sensing area
Sensing area (sensing condition)
1. When the sensing area detects
1.2 +/-15%pF or higher, extraction
operates. (Electrostatic capacity
4pF ~ 20pF)
2.
Extraction starts 100ms after the
human body contacts the sensing
area (when the condition 1 above is
met).
