1018028-BPage 23
Specications subject to change without notice.
PART DESCRIPTION
REF. #
PART NO. PART NO. PART NO. PART NO.
Propane Gas Model Numbers ........................
Natural Gas Model Numbers .........................
DVCF404C-H DVCF408C-H DVCF554C-H DVCF558C-H
DVCF403C-H DVCF407C-H DVCF553C-H DVCF557C-H
12 Burner 72107 72107 72107 72107
13 Valve, VR8200H-1004, Nat. W/78089 Dis. Bushing 78090 N/A 78090 N/A
13 Valve, VR8200H-1103, L.P. w/78089 Dis. Bushing 78091 N/A 78091 N/A
13b Valve, VR8204H-1006, Nat. w /78089 Dis. Bushing 13b N/A 78092 N/A 78092
13b Valve, VR8204H-1006 (Conv.), L.P. w/78089 Bushing N/A 78093 N/A 78093
N/A Disappearing Bushing, 1/2x3/8 78089 78089 78089 78089
14 Manifold 72103 72103 72103 72103
15 Burner Orice, Natural Gas 72147 72147 72140 72140
15 Burner Orice, L.P. Gas 72149 72149 72141 72141
23 Thermostat, 24 Volt 78355 78355 78355 78355
25 Pilot 0.140.512, Natural Gas (w/Electrode) 72020 N/A 72020 N/A
25 Pilot 0.140.502, L.P. Gas (w/Electrode) 72021 N/A 72021 N/A
25b / 28b Pilot Assy. Electronic w /Flame Ignitor Nat. N/A 78098 N/A 78098
25b / 28b Pilot Assy. Electronic w /Flame Ignitor L.P. N/A 78099 N/A 78099
27 Thermostat Wire 74518 74518 74518 74518
28 Thermocouple Q309A1954 78095 N/A 78095 N/A
29 Insulated Staples 74209 74209 74209 74209
N/A Power Cord 78213 78213 78213 78213
31 Sight Glass Assy. (Includes Cover & Gasket) 43252 43252 43252 43252
32 Sight Glass Cover 43258 43258 43258 43258
33 Sight Glass Gasket - 1-3/8x3”
34 Burner Box Gasket 72059 72059 72059 72059
41 Piezo Igniter
42 Igniter Wire 0.028.508 72022 N/A 72022 N/A
43 Ignition ControlBox S8600B, Honeywell N/A 78097 N/A 78097
N/A Elbow 3/8x90 Degree 84501 84501 84501 84501
53 Pilot Bracket 34440 34440 34440 34440
55 Manifold Gasket - 2x2”
56 Burner Access Door 34425 34425 34425 34425
57 Burner Access Gasket - 4x13”
58 Burner Box Bottom Assembly 34400 34400 34400 34400
N/A 90 Deg. Pilot Fitting N/A 70352 N/A 70352
59 Pilot Tube Gasket - 2-1/2x3/4”
60 Pilot Tube Bracket 34475 34475 34475 34475
N/A Vent Terminal Shield 34950 34950 34950 34950
N/A Pilot Tubing w/Fittings - 16” 78452 78452 78452 78452
N/A Lighting Instructions DVCF
* Requires 2 ** Requires 4
DIRECT VENT COUNTERFLOW WALL FURNACE PARTS LIST
Natural Gas: DVCF403C-H, DVCF553C-H, DVCF407C-H, DVCF557C-H
Propane Gas: DVCF404C-H, DVCF554C-H, DVCF408C-H, DVCF558C-H
