Craftex CT015N - Parts List

30
PARTS LIST
PART# DESCRIPTION QTY
1 Body 1
2 Arm 1
3 Hex Screw 1
4 Washer 1
5 Hex Nut 1
6 Pin 2
7 Cord Holder 2
8 Motor Cord 1
9 Power Cord 1
10 Bearing Base 1
11 Bearing 6203 2
12 *****
13 Key 5*5*20 1
14 Lock Washer 3
15 3-in-1 CAP Screw 4
16A Knob Bolt 5/16*1 1
17 Lock Washer 2
18 Pin 5*25 2
19 *****
20 *****
21 *****
22 *****
23 Flat Washer 3/8 8
24 CAP Screw 1/4*7/8 3
25 Bar Setting Plate 1
26 Spring 2
27 Flat Washer 5/16 2
28 Hex Screw 5/16*1 1/4 2
29 Nut 5/16 1
30 Guard Sleeve (L) 2
30A Guard Sleeve (S) 2
31 Hex Screw 3/8*2 4
32 Sliding Bracket 1
33A Blade Adjusting Screw 1
PART# DESCRIPTION QTY
34 Knob 1
35A Blade Guard 1
36 Spring 1
37 Square Nut 1
38 Shaft Hinge Assembly 1
39 Pan Screw 3/16*1/2 3
40 Steel Pin 2
41 *****
42 Inner Wheel Cover 1
43 *****
44 Screw 2
45 Bearing 6202 2
46 C-Ring R35 2
47 Upper Wheel 1
48 Wheel Protector 2
49 Hex Nut 1/2 1
50 Blade 1
51A Switch Plate 1
52 Switch 1
53A Upper Wheel Cover 1
54 Knob 5/16 4
55A Lower Wheel Cover 1
56 Set Screw 1/4*1/4
57 Hex Nut 3/4 (L.H.) 1
58 Lower Wheel 1
59 *****
60 *****
61 *****
62 Guide Post (L) 1
62A Guide Post (S) 1
63 Upper Support Bracket
– cast iron
1
64 *****
65 Hex Screw 1/4*5/8 1
66 *****
