Key Part No. Part No. Descriptions Specification
Qt
y
RIP FENCE ASSEMBLY
1 924774-000 PCX213001RF
Rip Fence
Assembly
1
.1 250483-615
PCX2130011R
F
End Cap 4
.2 310541-909
PCX2130012R
F
Adaptor 2
.3 000002-308
PCX2130013R
F
Hex. screw M6*1.0P*45 1
.4 171993-904
PCX2130014R
F
Bracket 1
.5 250602-621
PCX2130015R
F
Frictional Plate 1
.6 048701-101
PCX2130016R
F
Square Bolt M8*1.25P*20 6
.7 250470-620
PCX2130017R
F
Pointer 1
.8 006002-023
PCX2130018R
F
Flat Washer 6.3*13*2.0t 2
.9 000304-203
PCX2130019R
F
Pan Head Screw M6*1.0P*12 2
.10 174766-308
PCX21300110
RF
Fence Body 1
.11 008005-100
PCX21300111
RF
Hex Nut
M6*1.0P(10B*
5H)
1
.12 250587-615 PCX21300112 Frictional Wheel 1
