7
NOTE:
Please note that the riving knife will
need to be removed in certain instances
when you are not cutting through the
work piece entirely.
The supplied push stick is used to help
support the work piece as it passes by
the saw blade while keep your hands
safe and away from the blade helping to
reduce the risk of injury while performing
any cutting operations.
Grounding Instructions
PROPER GROUNDING
Grounding provides a path of least
resistance for electric current to reduce
the risk of electric shock.
CX213/CX214 is equipped with a 220-V
single phase motor and provided with a
power supply cord that is to be
connected directly to the source. See
figure-1.
Make sure that the machine is
connected to an outlet having the same
configuration. If an adaptor plug is
used, it must be attached to the metal
screw of the receptacle. To prevent
electrical hazards, have a qualified
electrician ensure that the line is
properly wired.
Figure-1 220-Volts Outlet for CX213/CX214
It is strongly recommended not to use
extension cords with your
CX213/CX214. Always try to position
your machine close to the power source
so that you do not need to use
extension cords.
When it is necessary to use an
extension cord, make sure the extension
cord does not exceed 50-feet in length
and the cord is 12-gauge to prevent
motor damage.
Your CX213/CX214 should be wired
with a plug having 3-prongs to fit a 3
prong grounded receptacle as shown in
figure 1.
Do not remove the grounding prong to fit
it into a 2 pronged outlet. Always check
with a qualified electrician if you are in
doubt.
WARNING!!!
Improper connection of the
equipment-grounding conductor can
result in a risk of electric shock.
Check with a qualified electrician if
you are in doubt as to whether the
outlet is properly grounded.
