Craftex CX series - Miter Gauge Assembly Parts

37
.17 360864-000
PCX21300217B
G
Pin 1
.18 360865-901
PCX21300218B
G
Spreader Shaft 1
.19 280160-901
PCX21300219B
G
Spring 1
.20 010204-000
PCX21300220B
G
Retaining Ring ETW-7 1
.21 280163-901
PCX21300221B
G
Spring 1
.22 171379-904
PCX21300222B
G
Anti-Kick Finger -
Right
1
.23 000303-110
PCX21300223B
G
Pan Head Screw M5*0.8P*30 1
.24 174397-904
PCX21300224B
G
Spreader 1
.25 575104-000
PCX21300225B
G
Warning Label 1
.26 000303-104
PCX21300226B
G
Pan Head Screw M5*0.8P*12 2
.27 006001-012
PCX21300227B
G
Flat Washer 5.3*12*1.0t 2
MITER GAUGE ASSEMBLY
3 924562-000
PCX213003MG Miter Gauge
Assembly
1
.1 230191-000 PCX2130031MG Handle 1
.2 006002-056 PCX2130032MG Flat Washer 8.5*23*2t 1
.3 310500-911 PCX2130033MG Plate 1
.4 003001-102 PCX2130034MG Hex. screw 1/4"20NC*1" 2
.5 090342-008 PCX2130035MG Miter gauge body 1
