PART NO. DESCRIPTIONREF NO
Auger Housing
Footnotes
Craftsman 22" Snowthrower C950-52844-1
Screw, 1/4-20 x 1.00 1 710263MA
Nut, Hex 1/4-20 2 73826MA
Screw, 1/4-20 x .75 3 302628MA
Washer, Flat 4 71067MA
Housing Assembly, Auger 5 1742262YP
Screw, 1/4-20 x .63 6 579052MA
Auger Assembly, 22" 7 1735771YP
Retainer, Bearing 8 580251MA
Bearing 9 43846MA
Sleeve, Spacer 10 578101MA
Plate, Bearing Retainer 11 334287MA
Pulley, Auger Drive V6 12 333446MA
Bearing, Flange 13 577023MA
Nut, Centerlock 1/4-20 14 73826MA
Blade, Auger. Black 15 1735606YP
Bracket, Center Auger 16 1735609YP
Nut, Nylock 17 1920397SM
Nut, Hex-Lock, ESNA Light, 5/16-18, NC38, Blavk 18 1919438SM
Shaft, Sub 19 1735610YP
Capscrew 20 5025299X8YP
Capscrew, Hex-Head, 5/16-x 1.5, G5 Black 21 1921221SM
PTS - 13
Not for
