REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
09A4130202E1
K Engine Gasket SetReference 358
D Carburetor Overhaul KitReference 121
Δ Valve Gasket SetReference 1095
Assemblies include all parts shown in frames. 08/05/2008
24
1 791356 Cylinder Assembly
2 399269 KitBushing/Seal
(Magneto Side)
3 K299819s SealOil
(Magneto Side)
5 790169 HeadCylinder
7 KΔ698717 GasketCylinder Head
8 791779 Breather Assembly
9 KΔ695890 GasketBreather
10 691666 Screw
(Breather Assembly)
12 K692218 GasketCrankcase
13 691640 Screw
(Cylinder Head)
14 690361 Stud
(Cylinder Head)
(Used In Position # 8)
15 691686 PlugOil Drain
16 793156 Crankshaft
18 699096 CoverCrankcase
20 K691356 SealOil
(PTO Side)
20B 299819s SealOil
(PTO Side)
21 281658s CapOil Fill
22 691129 Screw
(Crankcase
Cover/Sump)
 Note 
691128 Screw
(Crankcase
Cover/Sump)
(Used In Positions
Number 1 and 6)
23 699573 Flywheel
24 222698s KeyFlywheel
25 795691 Piston Assembly
(Standard)
 Note 
795689 Piston
Assembly
(.020” Oversize)
26 795690 Ring Set
(Standard)
 Note 
795688 Ring Set
(.020” Oversize)
27 691588 LockPiston Pin
28 699659 PinPiston
29 699655 RodConnecting
30 691719 Dipper
Connecting Rod
32 691664 Screw
(Connecting Rod)
33 497871 ValveExhaust
34 296677 ValveIntake
35 690520 SpringValve
(Intake)
36 690520 SpringValve
(Exhaust)
40
692194 RetainerValve
45 691762 TappetValve
46 691998 Camshaft
50 691922 ManifoldIntake
51 K273113s GasketIntake
54 691689 Screw
(Intake Manifold)
55 692144 Housing
Rewind Starter
58 697316 RopeStarter
60 691915 GripStarter Rope
65 690837 Screw
(Rewind Starter)
73 699850 ScreenRotating
81 691729 LockMuffler Screw
95 691636 Screw
(Throttle Valve)
97 496861 ShaftThrottle
104 D691242 PinFloat Hinge
108 695807 ValveChoke
109 695729 ShaftChoke
117 498978 JetMain
(Standard)
118 498975 JetMain
(High Altitiude)
121 498260 Kit
Carburetor Overhaul
122 699086 SpacerCarburetor
125 699103 Carburetor
127 D694468 PlugWelch
130 691203 ValveThrottle
133 398187 FloatCarburetor
134 D398188 KitNeedle/Seat
137 D693981 GasketFloat Bowl
177 691031 SealO Ring
(Dipstick)
186 692317 ConnectorHose
187 791766 LineFuel
(Cut to
Required Length)
188 691637 Screw
(Control Bracket)
202 692351 Link
Mechanical Governor
209 691858 SpringGovernor
(Yellow)
219 496786 GearGovernor
220 691724 Washer
(Governor Gear)
222 698681 BracketControl
227 691412 Lever
Governor Control
232 691846 SpringGovernor Link
276 D271716 WasherSealing
287 695733 Screw
(Dipstick Tube)
289 230228s PinStarter Grip
300 699565 Muffler
304 699093 HousingBlower
305 692198 Screw
(Blower Housing)
306 690461 ShieldCylinder
307 691660 Screw
(Cylinder Shield)
308 690462 CoverCylinder Head
309 699098 MotorStarter
332 690662 Nut
(Flywheel)
333 793281 ArmatureMagneto
334 691061 Screw
(Magneto Armature)
337 697451 PlugSpark
356 699576 WireStop
358C 794209 Gasket SetEngine
365 691688 Screw
(Carburetor)
404 691691 Washer
(Governor Crank)
415 693463 Plug
(Cylinder)
441 690484 BracketOil Fill
455 691236 CupFlywheel
456 692299 PlatePawl Friction
459 281505s PawlRatchet
505 691251 Nut
(Governor
Control Lever)
523 791205 Dipstick
524 691876 SealDipstick Tube
525 699090 TubeDipstick
529 692187 Grommet
552 690508 Bushing
Governor Crank
562 691119 Bolt
(Governor
Control Lever)
592 690800 Nut
(Rewind Starter)
