REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
09A4130202E1
K Engine Gasket SetReference 358
D Carburetor Overhaul KitReference 121
Δ Valve Gasket SetReference 1095
Assemblies include all parts shown in frames. 08/05/2008
25
597 691696 Screw
(Pawl Friction Plate)
601 791850 ClampHose
(Green)
608 699105 StarterRewind
613 691413 Screw
(Muffler)
614 691620 PinCotter
616 692016 CrankGovernor
633 D
z693867 Seal
Choke/Throttle Shaft
(Choke Shaft)
633A Dz691321 Seal
Choke/Throttle Shaft
(Throttle Shaft)
635 66538s BootSpark Plug
689 691855 SpringFriction
692 690572 SpringDetent
711 699470 Screw
(Carburetor Shield)
718 690959 PinLocating
(Cylinder)
718A 499047 PinLocating
(Crankshaft)
741 791124 GearTiming
772 691003 Screw
(Linkage Cover)
823 699554 Screw
(Muffler Adapter)
847 791204 Dipstick/Tube
Assembly
851 493880s TerminalSpark Plug
864 699568 AdapterMuffler
868 K697338 SealValve
869 699641 SeatValve
(Intake)
870 699642 SeatValve
(Exhaust)
871 699643 BushingValve Guide
883 691880 GasketExhaust
925 699097 CoverLinkage
975 493640 BowlFloat
976 394281s PrimerCarburetor
996 699099 ShieldCarburetor
1036 LabelEmissions
(Available From A
Briggs & Stratton
Authorized Dealer)
1095 498526 Gasket SetValve
1210 499901 Pulley/Spring
Assembly
(Pulley)
1211 499901 Pulley/Spring
Assembly
(Spring)
1320 691105 Nut
(Linkage Cover)
1330 270962 Repair Manual
