Toplacethenewbelt beginby routingthe beltaroundthe two
outerspindlepulleys,thenaroundthefront spindlepulleyas
shownin Figure15.
6. Thenroutethe beltaroundthetwodeckidlerpulleysasshownin
Figure15.
f
FrontSpindle
" Deck
Pulleys ....
Outer Spindle
Pulleys
Figure15
7. Retightenthe beltkeeperrodloosenedearlier.
8. Remountthebelt coversremovedearlier
9. Reinstallthe deckas follows:
a. Withthe deck beneaththemowerframe,attachthe stabilizer
rod.SeeFigure13.
b. Reconnectthedeck liftarms.SeeFigure12.
10. Pulltherightside ofthe beltandplacethe narrowV side of the
beltintothe PTOpulley.SeeFigure16.
PTO Belt
CHANGING THE TRANSMISSION DRIVE BELT
Severalcomponentsmustbe removedand specialtoolsusedinorder
tochangethe tractor'stransmissiondrivebelt.Seea Searsorother
qualifiedservicedealerto havethetransmissiondrivebeltreplaced.
CUTTING BLADES
Shuttheengineoff andremoveignitionkeybeforeremovingthe
cuttingblade(s)forsharpeningor replacement.Protectyourhands
usingheavygloveswhengraspingthe blade.
Periodicallyinspectthebladeand/orspindleforcracksordamage,
especiallyafter you'vestrucka foreignobject.Do notoperatethe
machineuntildamagedcomponentsare replaced.
Toremovetheblades,proceedas follows:
1. Removethe deckfrombeneaththe tractor,(referto CuttingDeck
Removalearlierinthissection)thengentlyflip thedeckoverto
exposeitsunderside.
2. Placea blockofwoodbetweenthecenterdeckhousingbaffle
andthe cuttingbladeto actas a stabilizer.
See Figure17.
f
FlangeLockNut
Block of Wood
)
Figure17
3. Removethe flangelocknutthat securesthe bladeto the spindle
assembly.SeeFigure17.
J
Figure16
11. Whileholdingthe beltandpulleytogether,rotatethepulleyto the
left(See Figure18).Continueholdingandrotatingthepulleyand
beltuntilthe beltis fullyrolledintothe PTOpulley.
12. Replacethe PTOpulleybeltguard.SeeFigure10.
22
