Crate LIMO TX50D User Manual

CRATE
3
FEA
TURES:
• Two separate channels
• Crate’s Digital Signal Processing (DSP)
• Insert jack for connecting external effects
• CD Inputs for connecting background music
• Footswitch control of channel selection and DSP on/off
• Headphones jack for silent operation
• Internal rechargeable power supply for up to 8 hours of normal play-
ing time, 2 hours at full output – fully recharges within 6 hours (when
battery is fully discharged; shorter if partially charged)
• Two-color battery status LED – red indicates low battery, yellow indi-
cates battery okay
• Can also be powered by an AC wall adapter (supplied) or by a 12 volt
vehicle car adapter (included – see page 5)
• Tuned port cabinet for extended bass response; 10” woofer and 2”
Piezo tweeter for full range sound with clear highs
• Durable black or platinum molded polymer enclosure
• Rubber feet on three sides – for positioning as a low angle monitor, a
high angle monitor or as an upright speaker (see below)
• Stand mount adapter (1-1/2” diameter) for PA use (see below)
LOW ANGLE MONITOR HIGH ANGLE MONITOR
UPRIGHT SPEAKER STAND MOUNTED SPEAKER

Crate LIMO TX50D Specifications

Power

output power rating	50W RMS @ 10% THD, 4 ohms, 13.6VDC in
power requirements	Internal 12 volt DC power supply
DC adapter	for use with 120VAC

Input and Output

input impedance	1M ohm
maximum signal accepted - Mic Low Z	2V peak to peak
maximum signal accepted - Mic Hi Z	12V peak to peak

Gain and Sensitivity

gain - Mic	57dB High Z, 72dB Low Z
gain - Instrument	44dB w/Gain switch out, Ch2, 85dB w/Gain switch in, Ch1

EQ Settings

EQS MIC Low	±15dB @ 60Hz
EQS MIC Mid	±15dB @ 600Hz
EQS MIC High	±15dB @ 10kHz

Size and Weight

width	15-1/2”
height	13”
depth	12”
