Crate LIMO TX50D User Manual

CRATE
5
ABOUT
THE POWER SUPPLY (continued):
The TX50DE may also be powered by using a 12-volt vehicle cigarette
lighter adapter, available at most electronic supply stores. Make certain
that the polarity on the adapter matches what is shown below.
Connect the small round end of the adapter to the 12VDC Automobile
adapter jack (#26, page 8), then connect the other end of the adapter
into the vehicle’s cigarette lighter socket. (In some vehicles, the ignition
switch must be in the “on” or “accessory” position to have power at the
socket.) NEVER PLUG THE SUPPLIED 15VDC CHARGER INTO THE
AMPLIFIER’S 12VDC LIGHTER PLUG!
When using the DC cigarette lighter adapter, the vehicle’s battery will
keep the amp charged to its own voltage level – if the battery has a
13.5-volt charge, the amp will charge up to 13.5 volts; if the battery is
low and only has a 10-volt charge, the amp will discharge down to 10
volts.
POSITIVE NEGATIVE

Crate LIMO TX50D Specifications

Power

output power rating	50W RMS @ 10% THD, 4 ohms, 13.6VDC in
power requirements	Internal 12 volt DC power supply
DC adapter	for use with 120VAC

Input and Output

input impedance	1M ohm
maximum signal accepted - Mic Low Z	2V peak to peak
maximum signal accepted - Mic Hi Z	12V peak to peak

Gain and Sensitivity

gain - Mic	57dB High Z, 72dB Low Z
gain - Instrument	44dB w/Gain switch out, Ch2, 85dB w/Gain switch in, Ch1

EQ Settings

EQS MIC Low	±15dB @ 60Hz
EQS MIC Mid	±15dB @ 600Hz
EQS MIC High	±15dB @ 10kHz

Size and Weight

width	15-1/2”
height	13”
depth	12”
