Creality Ender-3 Max User Manual

Product Introduction
设备简介
1
XE-axis kit XE轴组件
2
X-axis limit switch X轴限位开关
3
Print platform 打印平台
4
Z-axis limit switch Z轴限位开关
5
Nozzle kit 喷头套件
6
Z-axis passive block Z轴被动块
7
Screen 显示屏
8 Knob switch 旋钮开关
9
Power supply 电源
11
Filament detector 断料检测
10
Power switch and socke 电源开关及插座
12
Extruder 挤出机
13
E-axis motor E轴电机
14
Coupling 联轴器
15
Material rack and material tube 料架及料管
16
Z-axis motor Z轴电机
17
Machine base 机器底座
18
Y-axis motor Y轴电机
2
9
14
4
16
17
18
10
15
6
5
7
8
3
1
2
13
12
11

Creality Ender-3 Max Specifications

General

Build Volume	300 x 300 x 340 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Max Nozzle Temperature	260°C
Max Bed Temperature	100°C
Connectivity	SD card, USB
Technology	FDM (Fused Deposition Modeling)
Machine Dimensions	513 x 563 x 590 mm
Power Supply	350W
Printing Speed	180 mm/s
Supported Materials	PLA, ABS, TPU, PETG
Display	4.3-inch Color Touchscreen
