Creality Ender-3 Max User Manual

1
Put the gantry on the base, tighten and fix it with 4 M5*65 combination screws.
用4颗M5*65内六角圆柱头螺丝将龙门架放置于底座上,拧紧固定。
Install the Gantry Frame
安装龙门架
1
Printer base
I
底座组件 x 1
2
Gantry frame
I
龙门架 X 1
2
5
11
M5x65 socket head x 4
cap screws
M5x65内六角圆柱头螺丝
11
11
2
1

Creality Ender-3 Max Specifications

General

Build Volume	300 x 300 x 340 mm
Layer Resolution	0.1-0.4 mm
Filament Diameter	1.75 mm
Nozzle Diameter	0.4 mm
Max Nozzle Temperature	260°C
Max Bed Temperature	100°C
Connectivity	SD card, USB
Technology	FDM (Fused Deposition Modeling)
Machine Dimensions	513 x 563 x 590 mm
Power Supply	350W
Printing Speed	180 mm/s
Supported Materials	PLA, ABS, TPU, PETG
Display	4.3-inch Color Touchscreen
