Creative Cedar Designs Sky View 3101 - Phase 2: Fort Frame Assembly

Phase 2:
17
FORT FRAME ASSEMBLY
(12)
Fender Washer
Phase Hardware
Phase Parts
Note: It is IMPORTANT that the fort
be level after this
phase!
N
o
t
e
!
I
m
p
o
r
t
a
n
t
MAKE SURE FRAME IS
SQUARE BEFORE
PROCEEDING TO
NEXT PHASE!
1/8" Drill Bit
N
o
t
e
!
I
m
p
o
r
t
a
n
t
DRILL Ø1/8" PILOT HOLE
USE ATTACHMENT PIECE
HOLE AS A GUIDE
(2) 11/16 X 3 1/2 X 35 1/2 FLOOR SUPPORT - WA001-10
(2) 11/16 X 5 1/2 X 35 1/2 GROUND BOARD - WB003-10
FLUSH
FLUSH
35 1/2 O.D.
90°
35 1/2 O.D.
90°
2" LAG SCREW
FENDER WASHER
5/16" x 2" Lag Screws
(12)
