Creative Cedar Designs Sky View 3101 - Phase 21: Anchoring

Phase 21:
ANCHORING
Note: Failure to use stakes can void warranty & cause injury.
Final Step: Double check and make sure every bolt, screw
and nut is tight. Make sure every board is secure. Make sure
the fort is level and enjoy your playset.
STAKE STAKE
STAKESTAKE
36
Phase Hardware
Phase Parts
(4) 1-1/2’’ LAG BOLT
(4) FLAT WASHER
(4) ANCHOR PACK w/ HDW
BP001-B
1-1/2’’ LAG BOLT
FLAT WASHER
METAL STRAP
ANCHOR
*Place stakes into the ground next to playset as shown
