Creative Cedar Designs Sky View 3101 - Phase 9: Tarp Brace Installation

Phase 9:
24
Phase Parts
(2) 1 X 3 1/2 X 80 TARP CROSS BRACE - WC002-10
(2) 1 X 3 1/2 X 69 TARP UPRIGHT - WC003-10
T-NUTS
T-NUTS
90°
2 1/2" HEX BOLT
SPLIT WASHER
& FENDER WASHER
(6)
5/16" T-nuts
(6)
Fender Washer
(6)
5/16" Split Washers
Phase Hardware
(4)
5/16" x 2 1/2" Hex Bolts
2 1/2" HEX BOLT
SPLIT WASHER
& FENDER WASHER
(2)
5/16" x 2" Hex Bolts
1 1/2" T-20 Deck Screws
(2)
90°
TARP BRACE
INSTALLATION
90°
2" HEX BOLT
SPLIT WASHER
& FENDER WASHER
1 1/2" DECK SCREW
(INTO TOP WALL RAIL)
1 1/2" DECK SCREW
(INTO BOTTOM RAIL)
