Creative Cedar Designs Sky View 3101 - Phase 7: Rockwall & Ladder Attachment

Phase 7:
22
ROCKWALL & LADDER
ATTACHMENT
Phase Parts
Phase Hardware
1” Truss Head Screw
(4)
3/4" Tapping Screws
(4)
(4) GREEN L-BRACKET (SMALL) - M002
FLOOR
FLR. SUP.
1" TRUSS HEAD SCREW
THROUGH BRACKET INTO RAIL
3/4" #14 TAPPING SCREW
THROUGH BRACKET INTO FLOOR SUPPORT
CENTER ROCKWALL & DECKLADDER
IN THE AREAS SHOWN
POSITION ROCKWALL
& DECKLADDER
AS SHOWN
DO NOT OVER TIGHTEN TAPPING SCREWS!
ATTACH ROCKWALL IN LIKE MANNER
Important
Note!
Important
Note!
Important
Note!
HAND TIGHTEN
ALL TAPPING SCREWS
