Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Physical Description
Refer to the following illustrations. The CHV-TSTAT and CHV-THSTAT are in a
plastic enclosure with four buttons and an LCD display on the front. The back of the
unit has ventilation slots, and holes for mounting the unit and wiring. The ventilation
slots must be unobstructed for airflow to the unit.
Physical View of CHV-TSTAT and CHV-THSTAT
66
o
F
43
%
68
o
F
HEATING
HEAT ONLY
ON LINE
H1 H2 AX
Current Set Point (indicates
desired temperature, or
temperature range in auto
mode)
Current Activity
Current Function
System Information
- ON LINE (Cresnet on)
- HOLD (Cresnet off)
- NET FAULT (Net down)
- VIEW MSG (view
message)
- LOCKOUT (Network
lockout)
Internal Relay Status
Current
Temperature
Current Humidity
3.27 in
(8.29 cm)
3.38 in
(8.59 cm)
4.630 in
(11.76 cm)
3.75 in
(9.50 cm)
5.00 in
(12.70 cm)
MODE
VIEW
1.04 in
(2.63 cm)
0.47 in
(1.18 cm)
Front and Side Views
1.75 in
(4.44 cm)
R
ear View
4 • Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C

Crestron CHV-THSTAT Specifications

General

Brand	Crestron
Model	CHV-THSTAT
Category	Thermostat
Language	English
