Thermostats Crestron CHV-TSTAT and CHV-THSTAT
Slot 1- Heat/Cool Control Digital Joins - continued
SIGNAL I/O SIGNAL
TYPE
DEFINITION
Outdoor Temp Output Analog
Reports the temperature reading of any sensors set to "OD"
(Outdoor) in tenths of a degree. The scale (Fahrenheit or
Celsius) is based on the current setting in the unit. If more than
one sensor is set to OD, this is the mean outdoor temperature.
Sensors are manually set to Use, Omit, OD (Outdoor) or Slab
via the setup menus on the thermostat.
Slot 2 Detail View – Humidity Control
66 • Thermostats: CHV-TSTAT and CHV-THSTAT Operations and Installation Guide – DOC. 8163C
