DigitalMedia Switchers Product Manual – DOC. 8418A
Physical Description
The following sections provide information about the front and rear views of the
DM-MD8X8-CPU3, DM-MD16X16-CPU3, and DM-MD32X32-CPU3 and related redundant
power supply models (DM-MD8X8-CPU3-RPS, DM-MD16X16-CPU3-RPS, and
DM-MD32X32-CPU3-RPS).
Front View
This section provides information about the connectors, controls, and indicators on the
front of the DM-MD8X8-CPU3, DM-MD16X16-CPU3, and DM-MD32X32-CPU3 and
related RPS models.
DM-MD8X8-CPU3 Front View
