Crestron DMPS-100/200/300-C/300-C-AEC DigitalMedia Presentation System
Operations Guide – DOC. 7219D DigitalMedia Presentation Systems: DMPS-100/200/300-C/300-C-AEC • 41
Input Signal Type
The Input Sig. Type section of the “Audio Setup” menu is used to set the input signal
types to the AUD IN 1 through AUD IN 5 connectors as Auto, HDMI, or Analog.
NOTE: For inputs 3, 4, and 5, there is no audio output if the audio input type is set
to HDMI, and the video input type is set to something other than HDMI.
Access Input Signal Types
To access input signal types:
1. Access the “Audio Setup” menu as described on page 40. The words Input
Sig. Type are displayed.
“Audio Setup” Menu
Audio Setup
Input Sig. Type
j
2. Press ENTER to display the “Sel. Input Type” menu.
3. To return to the “Audio Setup” menu, press MENU.
Set the Signal Type
for Each Input
To set the signal types:
1. Access the “Sel. Input Type” menu as described above.
“Sel. Input Type” Menu
Sel.
Input Type
1:HDMI 1
j
2. Press the k and j buttons to select between 1:HDMI 1, 2:HDMI 2,
3:HDMI/VGA 3, 4:HDMI/VGA 4, and 5:HDMI/VGA/COMP signal source
types.
NOTE: Input 5 is not present on DMPS-100-C.
3. Press ENTER to confirm the selection. The LCD displays the “Select Input
1 Type” menu.
“Select Input 1 Type” Menu
Select Input
1 Type
*Auto
j
4. For each input type, press the k or j buttons to select between Auto,
HDMI, and Analog signal types. The 5:HDMI/VGA/COMP signal source
type menu offers a fourth signal type: S/PDIF. Press ENTER to confirm
the selection.
5. Repeat the above procedures to select the desired input signal type for each
input source type.
6. To return to the “Sel. Input Type” menu, press MENU.
