46 • DigitalMedia Presentation Systems: DMPS-100/200/300-C/300-C-AEC Operations Guide – DOC. 7219D
NOTE: Aux. 2 Output is not present on DMPS-100-C.
2. Press the k or j buttons until the Aux. 1 Output or Aux. 2 Output is
displayed on the LCD and press ENTER to display the “Aux. 1 Output” or
“Aux. 2 Output” menu.
3. To return to the “Audio Setup” menu, press MENU.
Set the
Auxiliary Output Source Mix
To set the auxiliary output source mix:
1. Access the “Aux. 1 Output” or “Aux. 2 Output” menu as described above.
2. Press the k or j buttons until Source Mix is displayed on the LCD and
press ENTER to display the “Aux. 1 Source Mix” menu.
“Aux. 1 Source Mix” Menu
Aux. 1 Source Mix
Aud. Only j
3. Press the k or j buttons until the desired setting is displayed on the LCD.
The current setting is indicated with an asterisk (*). The following settings
are available:
• Aud. Only: Sends the audio signal from the selected source to the
AUX OUT connector.
• Mic. Only: Sends the microphone input signals to the AUX OUT
connector.
• Mic + Aud: Sends a mix of the audio signal from the selected
source and the microphone input signals to the AUX OUT
connector.
NOTE: While setting the auxiliary output source mix, the auxiliary volume
level can be adjusted by turning the VOLUME control clockwise to raise
the volume, or counterclockwise to lower the volume. When adjusting the
volume, the display changes to indicate the volume level.
4. Press ENTER to save changes and return to the previous screen. To cancel
without saving changes, press MENU.
Set the
Auxiliary Output Bass Level
To set the auxiliary output bass level:
1. Access the “Aux. 1 Output” or “Aux. 2 Output” menu as described above.
2. Press the k or j buttons until Bass is displayed on the LCD and press
ENTER to display the “Aux. 1 Bass” menu. The current bass level is
displayed.
“Aux. 1 Bass” Menu
Aux. 1 Bass
k
0dB j
3. Adjust the auxiliary output bass level with the j and k buttons.
NOTE: While adjusting the auxiliary output bass level, the auxiliary
output volume level can be adjusted by turning the VOLUME control
clockwise to raise the volume, or counterclockwise to lower the volume.
