4 • TSW-560, TSW-760, and TSW-1060 Product Manual — Doc. 7927K
Access the Setup Screens
The setup screens enable basic configuration prior to regular operation of the touch screen.
NOTE: The TSW-560P 5 in. portrait touch screen provides the same setup screens that are
described in this guide, but the appearance and layout of the screens have been modified for
portrait orientation.
To access the setup screens during regular operation:
l Place five fingers on the touch screen display and hold for 15 seconds.
l Tap the hard keys labeled below as 1, 2, 3, and 4 in sequence twice (tap 1, 2, 3, 4, 1, 2, 3, 4) within
a 5-second period.
TouchScreen HardKeyAssignment
NOTE:The hard key button assignment for the TSW-560P differs from assignment
shown in the illustration above. For more information, refer to "Access the Setup Screens"
in the TSW-560P DO Guide (Doc. 7973) at www.crestron.com/manuals.

Crestron TSW-760 Specifications

General

Resolution	1280 x 800 pixels
Touch Technology	Capacitive
Network	10/100 Ethernet
Operating System	Crestron OS
Operating Temperature	32° to 104°F (0° to 40°C)
Memory	2 GB RAM
Display Size	7 in
Wi-Fi	802.11a/b/g/n
Bluetooth	Bluetooth 4.0
Power	PoE (Power over Ethernet)
Mounting	table top mount
