CTG2500i DIAGRAM
① Vent knob
② Fuel tank cap
③ Fuel tank
④ Handle
⑤ Recoil starter handlebar
⑥ Choke cable
⑦ Control panel
⑧ Muer
⑨ Main switch
⑩ Engine oil cover (Plug)
⑪ Drain screw, carburetor
⑫ Air lter cover
⑬ Spark plug cover
CONTROL PANEL
① Smart-throle switch (Eco-mode)
② 12V DC charging socket
③ DC protector
④ AC socket
⑤ AC socket
⑥ Ground (earth) bolt/nut
⑦ Low oil alarm
⑧ Over load alarm
⑨ Output indicator
⑩ Reset buon
ON/OFF SWITCH
① OFF - Ignion circuit and fuel
supply are o, and engine stops.
② ON - Ignion circuit and fuel
supply are on, and engine can be
started to work.
Pg. 12
