CARBURETOR ADJUSTMENT
Consult your local service agent for any adjustments on
the carburetor as special equipment is required for correct
adjustment.
SPARK PLUG INSPECTION
1. Remove spark plug cover and
spark plug cap.
① Spark plug cover
② Spark plug cap
2. Locate spark plug socket on spark
plug, turn it clockwise with wrench,
and then disassemble spark plug.
③ Spark plug socket
④ Spark plug
3. Check for discoloraon and remove the
carbon (Standard electrode color: Medium-
to-light tan color).
4. Check spark plug type and clearance.
Spark plug: A5RTC (TORCH)
Plug clearance: (a) 0.6mm
5. Install spark plug.
Plug torque: 12~15N.m
6. Install spark plug cover.
!
NOTE: When installing spark plug, twist it for 2-3
rounds by hand, and lock it up with specied torque value.
Pg. 25
