Chapter 1: About this manual
This manual provides informaon and procedures how to install and
setup the H & G+ series CTP
05
  
Contents
Typographic convenons
Chapter 2: Overview
2.1 Overview
04
Chapter 2: Overview
Chapter 3:Installaon site and environmental requirements
Chapter 4:Offloading, unboxing and installing
Chapter 5:Operaon instrucon
Chapter 6: Oponal device
Chapter 7:System maintenance
Chapter 8:Abnormal problems analysis and handling
Chapter 9:Vulnerable consumables and spare parts
Chapter 10:Appendixes
This document uses the following typographical convenons:
Calibri(Bold) Noun first defined and emphasis is indicated in bold
Calibri Represents the computer display of text and system items
Figure 2-1, H Model Figure2-2, G+ Model
a) CTP Computer To Plate is a laser imaging technology, that directly applies precision
bitmap informaon that processed by the RIP in Pre-press, on to digital offset plates by using
thermal laser ablaon or visible UV light exposing technique.Generally it consists of offset
plate mounng drum, opcal imaging system, laser driver system, scanning device, plate
mounng and releasing mechanism, vacuum adsorpon, dedusng device, the overall control
system and other components.
b) Depends on applicaons, CTP can be categorized as: Newsprint CTP (Resoluon:
1200~1800dpi), Commercial C TP (Resoluon: 1800~2800dpi), CommercialNews
CTP(1500~2540dpi)
c) There are 5 available CTP formats: 26series(max.format 670x570), 36series(max.format
925x675), 46series(max.format 1160x940), 60series(max.format 1524x1200),
72series(max.format 1850x1422)
d) Materials used are selecon of environmentally friendly materials and comply with
environmental laws and regulaons. We avoid using hazardous materials in the device and
strong abide to environmental proteconrequirements.
Figure illustraon as shown Pictures 2-1, 2-2:
CRON welcomes any valuable comments and suggestions:
CRON welcomes your comments and suggestions on this document, and it’s our sincere
commitment to provide upmost relevant detail in this document to meet your requirements.
To send in any comments or suggestions, please visit http://www.cron.com.cn.
When submitting comments and suggestions, attach the titleof the document, indicates page
number and any comments, errors or suggestions for improvement found in this document.
If you want to know the upgrade items during production,please refer to the announcements
by our company
SIMPLE AND DIRECT 丨 STEADY 丨 MAJOR
SIMPLE AND DIRECT 丨 STEADY 丨 MAJOR
NOTE: Photos for reference only as the device shapes are different
according to the configuation
