Cron TP26H - Power Connection & Wiring; Power Requirement; System Dimension & Weight

2.2 System dimension & weight
Table 2-1:System equipment size, weight table
2.4Power connecon & wiring
2.4.1 Preparaon of the wires, sockets, open empty, etc. (if necessary, an UPS is required too)
Picture 2-4: power wiring diagram
Remark：System equipment, size, weight will be vary depends on required configuraons.
W（cm）
L（cm）
H（cm）
Output Bridge
（cm）
Loading Table
（cm）
Weight
（≈kg）
2.3Power requirement
Table 2-2：Power requirements of the system
2.4.2 Device grounding connection terminal located inside the machine(near
power supply input section), check and confirm grounding terminal point,
make sure ground cable is properly connects to the terminal point(36/46/60
series)
Device Model
TP26H/TP26G+
TP36H/TP36G+
TP46H/TP46G+
TP60H/TP60G+
TP72H/TP72G+
140
165
190
230
270
111
106
122
130
134
105
107
110
118
110
55
55
55
60
95
60/45
55/50
98/70
90
144
815
1150
1280
1650
2480
Rated power（kw）
Power supply requirements
Device Model
TP26H/TP26G+
TP36H/TP36G+
TP46H/TP46G+
TP60H/TP60G+
TP72H/TP72G+
5.3/4.3
5.6/4.5
5.6/4.5
6.6/5.3
8.8/7.8
200~240V 25A
200~240V 25A
200~240V 25A
3-360~400V 10A
3-360~400V 17A
Picture 2-4:power wiring diagram
Chapter 2: Overview
a) Remove the device lower right casing,
and locate the ground terminal connector
indicated with label
b) Remove the inner panel that cover the
high voltage section, direct the ground
cable into the device through this section
and connect to the ground terminal
connector(36/46/60series)
c) For 26series CTP, ground terminal
connection point is located at the lower rear
casing of the device(at the back of CTP
near the power input box section,
Instrucon：Required voltage must be stable. Grounding must be good (with galvanized metal diameter of not
less than 10mm, buried 1.5m below).Equipment must be having ground resistance ≤ 0.5Ω.
