Chapter 4: Offloading, Unboxing and Installing
4.1 On-site condions during offload handling
4.5 Unboxing, fixing and installing
Table 4.1, The following table lists the package sizes and weight of different models
4.2 Shipment packing
4.3 Loading &unloading equipment
4.4 Installaon personnel
  
TP/UVP****H
TP/UVP****G+
Device Model
Packing
Single Crate
TP26H/TP26G+
TP36H/TP36G+
TP46H/TP46G+
TP60H/TP60G+
TP72H/TP72G+
170
190
210
260
290/118
139
139
143
148
156/94
900
1300
1450
1800
2650/240
W（cm）
L（cm）
H（cm）
Weight（≈kg）
Dual Crates
155
154
170
200
166/75
4.5.1 Unboxing flow chart
Customer needs to provide handling equipment and tools to ensure the safe handling of the machine to the installation
site.In the meantime, CRON engineers will assist with the handling and uncrating on site.
Depend on CTP series/model, standard packing could uses 1 to 2 crates.
Single Crate
Single Crate
Single Crate
Customers must provide forklift or crane with minimum load-bearing for more than 2000kg(72
model ＞5000Kg）. Forks length must be more than 150cm. If necessary, lengthen the span of
two forks according to the wooden box and the structure of the machine to adjust to the
corresponding width.
CRON advised customer to provide professional handling personnel to move the machine to
the premises of installation and unpack the crate, with CRON professionals work together on site.
Uncrate the box
Remove aluminium foil
Remove accessories
Lifting&positioning
Device levelling
Remove fixing bracket
Connect to optional
device(AL/BGP)
END
Uncrate the box
Remove aluminium foil
Remove accessories
Lifting&positioning
Device levelling
Remove fixing bracket
Connect to optional
device(AL/BGP)
END
