Cron TP26H - Page 8

4.5.2 Unboxing preparaon
4.5.3 Uncrate the box
  
Table 1:Wooden crate panels list
4.5.5 Removal of aluminium foil
Aluminium foil
Equipment fixing brackets figures
Descripon
Material/ Specificaon Qty
Note
4
Equipment
Wooden box end panels
4.5.6 Remove of bundled accessories
4.5.7 Device posioning and removal of air pump fixing screws
No
1
1
2
2
1
1
2
3
5
Wooden box pallet
Wooden box side panels
Wooden box cover
Wood layers
4.5.4
Figure 3: Panels removal instrucons
locked stage
unlocked stage
Figure 4: Aluminium foil and equipment fixing brackets figures
Chapter 4: Offloading, Unboxing and Installing
First of all, check the crate box is intact, lt indicator whether has any toner presence of overflowbeyond the
guide line. Ifproblems are found, they should be documented and feedback to CRONimmediately.
Follow the steps to remove the wooden box cover, side panels and pallet
base(shown in Figure 3 and Table 1)
Use long-nose pliers to loosen the wooden case lock
Wood layers
Wood layers
Wood layers
Cut the foil bag at the boom in circle, then remove foil bag (Figure 4).Be careful not to scratch the
equipment while cung the foil bag.Then unscrew the hex screws 8-M6 * 10, unscrew the nut 4-
M10,remove the fixing brackets(Figure 4)
Note: Depends on season and modes of transportaon, method of packing could be done either
withwrapping bag, and/or aluminum foil bag. The descripon here refers of an aluminum foil bag as an
example
Find the opening and remove of stretch film, remove the equipment spare parts and accessories and keep it
in a safe place for later use.
a) While using a forkli to li up the HDI device, length of folds should be
beyond the center gravity of the device, and forks ps should be kept out of
the wooden pallet base. Keep aenon and maintain stable while shovel
and liing the device. Moves the device to the installaon locaon and
carefully lower it down onto the ground;
b) While having the device liing up by the forkli, rremove the vacuum
pumps(compressors) fixing screws from underneath the device;
c) Moves the device to the installaon locaon and carefully lower it
down onto the ground;
1514
