K Series Service ManualRev A.
Exploded View Parts 7-7
©1999 Crown International, Inc.
1 Back Panel, K2 101085-X 1
1 Back Panel, K1 102013-X 1
2 Main PCA 100497-X 1 Complete
3 Input PCA, K1 101809-X 1 Complete
3 Input PCA, K2 100524-X 1 Complete
4 Line Filter PWA 101014-X 1 *
5 Lockwasher, #6 Int. Star A10094-3 7
6 Terminal, Dual Binding Post C10184-7 2 w/hardware
7 Screw, 6-32 X .375 PNHD T15 A12148-70606 7
8 8-32 Hex Nut A10102-6 1
9 Fuseholder, 3AG–Scrdvr–Slot 100850-1 1
9X Fuse See Chapter 4 1
10 Strain Relief A10214-10 1
11 Lockwasher, #10 Int. Star A10094-8 6
12 Screw, #4 X .5 PNHD PH A10111-70408 4
13 Power Cord:
A1/E3/E8/E17/Dom. (Nema 5-15) 101011-2 1
E13 Models (Schuko plug) A10793-0508T 1
E14 Models (BS 1363 plug) A10793-0608T 1
E24 Models (Old BS plug) A10793-0708T 1
E34 Models (Australia) A10793-0908T 1
14 Nut, Phone Jk 1/4" PC Mount C10226-1 2
15 PC Board Support, 1" 100939-1 1
16 Output Wires 100537-1 2 w/connectors
17 Wire (feedback) A11382-F040L 2 w/connectors
18 Wire (Line Filter Power) A11384-C020M 1 w/connectors
19 Blk Wire (Control Power) P8 A11384-C095M 1 w/connectors *
Wht Wire (Control Power) P9 A11565-A095M 1 w/connectors *
Item # Description Part # (CPN) Qty. Notes
7.4 Back Panel Assembly
Refer to figure 7.3 for Exploded View
* Denotes part used with early, non-CE models only
