Crown Macro-Tech MA-5002VZ

Module Parts 9-51
130446-1 Rev. A
MA-5002VZ Service Manual
©2000 Crown International, Inc
Capacitors
C513 0.022 µfd C 5671-0
C521 0.022 µfd C 5671-0
Diodes
D508 MR822 C 8383-9
D509 MR822 C 8383-9
Resistors
R523 0.33 ohm 5 W C 8787-1
R525 0.33 ohm 5 W C 8787-1
R527 0.33 ohm 5 W C 8787-1
R529 12 ohm 12 W A10266-1204
R535 12 ohm 12 W A10266-1204
R537 0.33 ohm 5 W C 8787-1
R539 0.33 ohm 5 W C 8787-1
R541 0.33 ohm 5 W C 8787-1
R581 0.33 ohm 5 W C 8787-1
R583 0.33 ohm 5 W C 8787-1
Q42934-2 Negative Emitter PWA
Circuit
Designation
Component
Description
Part
Number
Applicability
& Notes
PWB: P10342-7, Schematic: J0488-7
