MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-21
©2000 Crown International, Inc.
Figure 7.11 Main Module Tray Assembly
7.11 Main Board Tray Assembly
NotesItem # QTY Part Number Description
1 1 100110-1 Main Board Tray
2 1 See Section 8 Main Module See Section 8.
3 6 A10094-4 #6 Int. Star Washer
4 6 A10086-10604 6-32x.25 Machine Screw Phillips, round-head
To Next Page
