Introduction 1-1
130446-1 Rev. A
MA-5002VZ Service Manual
©2000 Crown International, Inc.
1.1 Introduction
This manual contains complete service information on
the
Crown
®
MA-5002VZ power amplifier. It is designed
to be used in conjunction with the Reference Manual;
however, some important information is duplicated in
this Service Manual in case the Reference Manual is
not readily available.
NOTE: THE INFORMATION IN THIS MANUAL IS
INTENDED FOR USE BY AN EXPERIENCED TECH-
NICIAN ONLY!
1.2 The MA “02” Series Amplifiers
The
Macro-Tech
®
series is a complete family of ampli-
fiers designed for pro sound reinforcement. Macro-
Tech amplifiers are designed to provide enormous lev-
els of pure, undistorted power in a rugged low-profile
package, utilizing Crown's patented
Grounded
Bridge
™ output topology. They also employ Crown's
patented
ODEP
®
protection circuitry, which keeps the
amplifier working under extreme conditions that would
shut down a lesser amplifier. Crown's new
Macro-Tech
“02” series amplifiers feature Crown's enhanced
PIP2
™
(Programmable Input Processor) expansion
system. The
PIP2
expansion system makes it easy to
tailor the amplifier to a specific application. Providing
high power amplification from 20 Hz to 20 kHz with
minimum distortion, Macro-Tech series amplifiers fea-
ture balanced inputs with bridged and parallel mono-
phonic capability. The MA-5002VZ includes additional
features not found on other Macro-Tech series models
including switchable compression, switchable loud-
speaker offset integration (LOI), and I
LOAD/ILIMIT indi-
cation.
1.3 Scope
This Service Manual in intended to apply to all ver-
sions of the MA-5002VZ amplifier. The Parts Listings
include parts specific for the US version and the Euro-
pean version (E13). For parts specific only to other
versions contact the Crown Technical Support Group
for help in finding part numbers.
1.4 Warranty
Each Reference Manual contains basic policies as re-
lated to the customer. In addition, it should be stated
that this service documentation is meant to be used
only by properly trained personnel. Because most
Crown products carry a 3-Year Full Warranty (includ-
ing round trip shipping within the United States), all
warranty service should be referred to the Crown Fac-
tory or Authorized Warranty Service Center. See the
applicable Reference Manual for warranty details. To
find the location of the nearest Authorized Warranty
Service Center or to obtain instructions for receiving
Crown Factory Service, please contact the Crown Tech-
nical Support Group (within North America), or your
Crown/Amcron Importer (outside North America). If you
are an Authorized Warranty Service Center and have
questions regarding the warranty of a product, please
contact the Field Service Manager or the Technical
Support Group.
Crown Customer Service
Technical Support Group
Factory Service
Parts Department
Mailing Address:
P.O. Box 1000, Elkhart IN 46515
Shipping Address:
Plant 2 S. W.
1718 W. Mishawaka Rd., Elkhart IN 46517
Phone: (219) 294-8200
Toll Free: (800) 342-6939
Fax: (219) 294-8301
http://www.crownaudio.com
