Crown Macro-Tech MA-5002VZ

Module Parts 9-53
130446-1 Rev. A
MA-5002VZ Service Manual
©2000 Crown International, Inc
Q42935-9 Positive Emitter PWA
Circuit
Designation
Component
Description
Part
Number
Applicability
& Notes
PWB: P10336-9, Schematic: J0488-7
Capacitors
C512 0.022 µfd C 5671-0
C520 0.022 µfd C 5671-0
Diodes
D506 MR822 C 8383-9
D507 MR822 C 8383-9
Resistors
R522 0.33 ohm 5W C 8787-1
R524 0.33 ohm 5 W C 8787-1
R526 0.33 ohm 5 W C 8787-1
R528 12 ohm 12 W A10266-1204
R534 12 ohm 12 W A10266-1204
R536 0.33 ohm 5 W C 8787-1
R538 0.33 ohm 5 W C 8787-1
R540 0.33 ohm 5W C 8787-1
R580 0.33 ohm 5 W C 8787-1
R582 0.33 ohm 5 W C 8787-1
