MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-5
©2000 Crown International, Inc.
7.2 Front Chassis Assembly
1 1 F12701-3 Chassis
2 4 A10089-11032 Screw, 10-32 X 2
3 4 A10094-8 Washer, #10 Int. Tooth
4 4 A10094-5 Washer, #8 Int. Tooth
5 4 C 8874-7 Screw, 8-18 X .375 Sht mtl
6 3 A10092-10607 Screw, 6-32 X .437 Socket
7 1 --- Transformer Bracket See Transformer Assembly, Section 7.6
8 2 C 8507-3 Screw, 8-32 X 1 Flat Hd
9 1 F12888-8 Front Panel
10 1 128304-1 MA-5002VZ Lexan Overlay
11 2 C 8776J3 Handle
12 2 D 6265-9 Knob
13 2 C 6005-0 Set Screw, 6-32 X .18
14 2 --- Nut Part of item 23
15 2 --- Washer Part of item 23
16 7 D 7937-2 LED Collar
17 1 D 7872-1 Pushbutton
18 1 D 4108-3 Pushbutton Collar
19 5 D 7696-4 Foam Filter
20 20 B 5796-6 Velcro .5" x .25"
21 4 C 7965-4 Screw, 8-32 X .37 Flat Hd
22 1 D 7791J2 Grille Extrusion
23 2 C 7280-8 5K ohm Level Pots Includes hardware items 14 and 15
24 2 D 7792J0 Panel Cap
25 2 D 7793J8 End Cap
NotesItem # QTY Part Number Description
