Crown Macro-Tech MA-5002VZ

MA-5002VZ Service Manual130446-1 Rev A
Exploded View Parts 7-13
©2000 Crown International, Inc.
7.6 Transformer Assembly
1 4 C10332-2 Bridge Rectifier, 50A EDI
2 1 Control Module See Section 8.
3 1 Q42929-2 Display Module See Section 8.
4 3 C 8852-3 0.5" PC Board Support
5 1 F12813-6 XFMR/Sub-front Bracket
6 2 D 9019-7 Main Power Toroid XFMR
7 2 C 8919-0 0.5" Steel Bolt
8 2 A10095-7 0.5" Ext. Lockwasher
9 2 A10102-21 0.5" Hex Nut
10 1 C10180-5 DPST 6A Pushbutton Switch
11 2 C 5961-5 4-40 X .375 Taptite
12 7 A10094-4 #6 Int. Star Washer
13 7 A10086-10608 6-32x.5 Machine Screw
14 4 A10098-3 #8 HDS-4 Saftey Washer
15 4 A10102-6 8x32 Hex Nut
16 2 A10100-25 0.5" Plain Steel Washer
NotesItem # QTY Part Number Description
