Cryo-con 24C - Page 185

Cryo-con Model 24C Appendix G: Sensor Data Tables
Thermocouples
An external thermocouple module is
required.
Thermocouple Type E
Name: TC type E Config: TC70
K μV μV/K
3.2 -9834.9 1.59
4.2 -9833 2.09
10 -9813.3 4.66
20 -9747 8.51
30 -9643.8 12.1
40 -9505.5 15.5
50 -9334.2 18.7
75 -8777.7 25.6
100 -8063.4 31.4
150 -6238.1 41.2
200 -3967.4 49.3
250 -1328.7 56
273.15 0 58.5
300 1608 61.1
350 4777.7 65.6
400 8159.8 69.6
500 15426 75.3
600 23138 78.6
670 28694 80
700 31100 80.4
800 39179 81
900 47256 80.4
1000 55247 79.3
1100 63119 78.1
1200 70842 76.3
1270 76136 75.2
Thermocouple Type K
Name: TC type K Config: TC70
K μV μV/K
3.2 -6457.7 0.74
4.2 -6456.9 0.92
10 -6448.5 2.01
10.5 -6447.4 2.12
20 -6417.8 4.15
30 -6365.1 6.39
40 -6290 8.61
50 -6193.3 10.7
75 -5862.9 15.6
100 -5417.6 19.9
150 -4225.5 27.5
200 -2692.8 33.5
250 -897.6 38
273.15 0 39.4
300 1075.3 40.6
350 3135.8 41.5
400 5200 40.8
500 9215.6 40.3
600 13325 41.7
670 16264 42.2
700 17533 42.4
800 21789 42.6
900 26045 42.4
1000 30251 41.7
1100 34373 40.7
1200 38396 39.7
1270 41153 39
1300 42318 38.7
1400 46131 37.5
1500 49813 36.1
1600 53343 34.5
1640 54712 34
