Cryo-con Model 24C Appendix G: Sensor Data Tables
Thermocouple Type T
Name: TC type T Config: TC70
K μV μV/K
3.2 -6257.5 1.03
4.2 -6256.2 1.4
10 -6242.9 3.12
20 -6199.2 5.58
30 -6131.3 7.99
40 -6040 10.2
50 -5927.7 12.2
75 -5573.6 16
100 -5131.2 19.4
150 -4004.3 25.6
200 -2575.3 31.4
250 -872.57 38
273.15 0 39.4
300 1067.4 40.8
350 3215.5 45
400 5560.2 48.7
500 10735 54.6
600 16437 59.2
670 20677 61.7
Thermocouple Type Chromel-AuFe(0.07%)
Name: AuFe 0.07% Config: TC70
K μV μV/K
1.2 -5299.6 8.98
2 -5292 10.1
3.2 -5278.9 11.6
4.2 -5266.8 12.6
10 -5181.8 16
20 -5014 17
30 -4846.4 16.6
40 -4681.5 16.5
50 -4515.8 16.7
75 -4084.6 17.8
100 -3627 18.8
150 -2645.2 20.4
200 -1600.1 21.4
250 -512.81 22
300 597.44 22.4
350 1696.3 21.8
400 2805.7 22.7
500 5135.3 23.4
600 7470.7 23.4
