AirData 150 S2 USB User Manual
40
Each NIC Wireless has only one PIN Code of Enrollee.
Config Mode: It illustrates the station role-playing as an Enrollee or an external Registrar.
WPS Profile List: Display all of the credentials got from the Registrar. List information
includes SSID, MAC address, Authentication and Encryption Type. If STA Enrollee,
credentials are created as soon as each WPS success. If STA Registrar, RaUI creates a new
credential with WPA2-PSK/AES/64Hex-Key and doesn’t change until next switching to STA
Registrar.
Control items on WPS Profile List:
Î Detail: Information about Security and Key in the credential
Î Connect: Command to connect to the selected network inside credentials. The
active selected credential is as like as the active selected Profile.
Î Rotate: Command to rotate to connect to the next inside credentials
Î Disconnect: Stop WPS action and disconnect the active link. And then select the
last profile at the Profile Page of RaUI if exist. If there is an empty profile page, the driver
will select any non-security AP.
Î Delete: Delete an existing credential. Select the next credential if it exists. If there
is an empty credential, the driver will select any non-security AP.
PIN: Start to add to Registrar using PIN configuration method. IF STA Registrar, remember to
enter the PIN Code read from you Enrollee before starting PIN.
PBC: Start to add to AP using PBC configuration method.
When you click PIN or PBC, please don’t do any rescan within two-minute connection. If you
want to abort this setup within the interval, restart PIN/PBC or press Disconnect to stop WPS
connection.
WPS associate IE: Send the association request with WPS IE during WPS setup. It is
optional for STA.
WPS probe IE: Send the probe request with WPS IE during WPS setup. IT is optional for
STA.
Progress Bar: Display rate of progress from Start to Connected status.
Status Bar: Display the current WPS Status.
[WPS Information on AP]
WPS information contain authentication type, encryption type, config methods, device
password ID, selected registrar, state, version, AP setup locked, UUID-E and RF bands.
Authentication Type: There are three types of authentication modes supported by RaConfig.
The available options are Open, Shared, WPA-PSK, and WPA system.
Encryption Type: For Open and shared authentication mode, the selection of encryption are
None and WEP. For WPA, WPA2, WPA-PSK, and WPA2-PSK authentication mode, the
encryption type supports both TKIP and AES.
